Arduino Nano Clone
Arduino Nano Clone
Regular price
$11.99 USD
Regular price
Sale price
$11.99 USD
Unit price
/
per
Couldn't load pickup availability
Share
Description
This Arduino Nano Clone offers the same features as the official Nano R3, with the ATmega328P microcontroller in a compact, breadboard-friendly layout. It uses the CH340 USB-to-serial chip, so a driver install may be needed. Ideal for space-constrained projects and rapid prototyping with sensors, displays, and modules.
Specs
| Specification | Value |
| Microcontroller | ATmega328P |
| Operating Voltage | 5V |
| Input Voltage | 6–20V |
| Recommended Input Voltage | 7–12V |
| Digital I/O Pins | 14 |
| PWM Channels | 6 |
| Analog Input Pins | 8 |
| Flash Memory | 32 KB (2 KB used by bootloader) |
| SRAM | 2 KB |
| EEPROM | 1 KB |
| Clock Speed | 16 MHz |
| USB-to-Serial Chip | CH340 or FT232 |
| USB Connector Type | Mini USB |
| Board Dimensions | ~45 mm × 18 mm |
| Breadboard Compatible | Yes |
Compatibility
- Works with Arduino IDE and PlatformIO
- Compatible with sensors, OLEDs, relays, motor drivers
- Perfect for wearables, robotics, and embedded systems
Resources
- 🔌 CH340 Driver (Nano Clones)
Download Drivers - 🧰 Nano Pinout Diagram
Pinout & Info - 🎓 Beginner Nano Project Guide
Project Hub (Nano)
This Arduino Nano-compatible board is a compact and cost-effective clone based on the ATmega328P microcontroller, ideal for space-constrained projects like wearables and embedded systems. It provides 14 digital I/O pins, 8 analog inputs, PWM output support, and is easily programmable via a mini-USB connection. Fully compatible with the Arduino IDE, this clone is a solid choice for both beginners and experienced users working on prototyping, robotics, or IoT applications.
