Arduino Leonardo with Headers Clone

Description

This Arduino Leonardo Clone replicates the functionality of the official board using the ATmega32u4 microcontroller, which features built-in USB support. It can emulate a keyboard, mouse, or joystick directly via USB — making it unique for HID projects. Compatible with the Arduino IDE and most Leonardo libraries.

Specs

Specification	Value
Microcontroller	ATmega32u4
Operating Voltage	5V
Input Voltage (recommended)	7–12V
Digital I/O Pins	20
PWM Channels	7
Analog Input Pins	12
Flash Memory	32 KB (4 KB for bootloader)
SRAM	2.5 KB
EEPROM	1 KB
Clock Speed	16 MHz
USB-to-Serial Chip	None – native USB
USB Connector	Micro USB
Board Dimensions	68.6 mm × 53.3 mm

Compatibility

• Supports USB HID (keyboard/mouse emulation)
• Compatible with Arduino IDE
• Great for custom input devices, gamepads, and HID automation

Resources

• 🧰 Leonardo HID Projects Tutorial
  Arduino HID Reference
• 📘 Leonardo Pinout Diagram
  View Pin Mapping
• 📺 YouTube: USB Keyboard with Leonardo
  Watch Tutorial

Description
This Arduino Leonardo-compatible clone is a feature-rich microcontroller board based on the ATmega32u4, offering native USB communication without the need for a separate USB-to-serial chip. Pre-soldered with standard headers, it's ready for easy integration with breadboards and external components. The board provides 20 digital I/O pins (including 7 PWM channels), 12 analog inputs, and can emulate USB devices like a keyboard or mouse—making it ideal for HID projects, interactive designs, and rapid prototyping. Fully compatible with the Arduino IDE, this Leonardo clone delivers powerful functionality at a lower cost.
